| Coupling of Inductors |
Back to the index Back to the top of index |
Goal: |
Make a mutual coupling between inductors. |
| What to do: | Select Lyis the name of the primary inductor (Starting with L) Lz is the name of the secondary inductor (Starting with L) kmutual coupling (0<k<1), see the Reference Guide. |
| Result: | Mutual coupling between inductors. |
Note: |
You can make multiple couplings to create multiphase transformers. |
 |
